Name: Stator SD 6-3 TDBS Slimline
Brand: No brand
SKU: 00100556
Price: 2705 UAH
Availability: PreOrder

Stator SD 6-3 TDBS Slimline

SKU: 00100556

53.00 EUR

Specification

Type of equipment	PFT G4, PFT Ritmo L +, PFT Ritmo L Plus, PFT MONOJET, MIXXMANN S8, MIXXMANN S6, MIXXMANN S7, SWING L, PFT Ritmo XL
Brand	No brand
Type	SD 6-3
Application	For adhesive solutions, For joint filling compounds, For reinforcing solutions, For heat-insulating plaster, For lime-cement plaster < 3 mm, For light plastering, For gypsum/gypsum-lime plaster, For finishing plaster (mineral), For clay plaster (dry), For fire retardant mortars, For poured floors, For thin poured floors, For finishing plaster (paste)
Working pressure	25 bar
Length	273 mm
Diameter	90 mm
Power at 400/200 rpm	18/10 l/min

Description

Stator SD 6-3 TDBS Slimline is the working element of the screw pair in the plastering station and operates together with the corresponding rotor. The stactor’s design enables the transportation of construction mixtures through the pumping unit and creates the necessary pressure during their delivery.

The SD 6-3 Slimline model is designed for PFT plastering machines with a power supply of 230 V, particularly the G 4, RITMO XL, and SWING L. The stator is used for working with various construction mixtures, including gypsum, gypsum-lime, lime-cement plasters, adhesives, and reinforcement compounds.

The stator has a length of 273 mm and a diameter of 90 mm. The maximum grain size of the mixture is 2 mm, the output of the screw pair is up to 20 l/min, and the working pressure is up to 25 bar.

Type: screw pair stator.

Model: SD 6-3 Slimline.

Length: 273 mm.

Diameter: 90 mm.

Maximum grain size: 2 mm.

Output: up to 20 l/min.

Working pressure: up to 25 bar.

Application: PFT G 4, PFT RITMO XL, PFT SWING L.

Purpose: delivery of plaster and other construction mixtures.
