Name: Rotor SD 6-3 TDBS Slimline
Brand: No brand
SKU: 00100557
Price: 2905 UAH
Availability: PreOrder

Rotor SD 6-3 TDBS Slimline

SKU: 00100557

57.00 EUR

Specification

Type of equipment	PFT Ritmo L +, PFT MONOJET, MIXXMANN S8, MIXXMANN S6, MIXXMANN S7, SWING L, PFT G4, PFT Ritmo XL
Brand	No brand
Type	SD 6-3
Application	For lime-cement plaster < 3 mm, For finishing plaster (paste), For finishing plaster (mineral), For light plastering, For gypsum/gypsum-lime plaster, For heat-insulating plaster, For adhesive solutions, For reinforcing solutions, For fire retardant mortars, For clay plaster (dry), For thin poured floors, For poured floors, For joint filling compounds
Working pressure	25 bar
Power at 400/200 rpm	18/10 l/min

Description

Rotor SD 6-3 TDBS Slimline is designed to work as part of a screw pair with the stator SD 6-3 Slimline. It is used in plastering stations and pumping equipment for the continuous supply of building mixtures.

The rotor operates in conjunction with the stator, forming working chambers for the transportation of material. The SD 6-3 Slimline system is designed to work with gypsum and gypsum-lime plasters, lightweight plasters, lime-cement mixtures, adhesives, reinforcing and finishing compounds, fillers, and other building materials of appropriate granulation.

The screw pair SD 6-3 Slimline provides a performance of 20 l/min at 400 rpm and 10 l/min at 200 rpm. The maximum grain size of the material is 2 mm, and the working pressure is up to 20 bar.

The rotor is used with plastering stations PFT G 4, RITMO XL, and SWING L, equipped with the corresponding screw system SD 6-3 Slimline.

Type: rotor of the screw pair.

Model: SD 6-3 Slimline.

Compatible stator: SD 6-3 Slimline.

Working pressure: up to 20 bar.

Performance: 10 l/min at 200 rpm; 20 l/min at 400 rpm.

Maximum grain size of the material: 2 mm.

Type of connection of the screw pair: D.

Application: PFT G 4, RITMO XL, SWING L.

Purpose: supply of plaster and building mixtures.
